mosaic-G5 P3H Dual Channel M.2 socket RTK GNSS receiver
mosaic-G5 P3H Dual Channel M.2 socket RTK GNSS receiver
Tax excluded
mosaic-G5 P3H M.2 socket dual channel all-constellation multi-frequency top-performance high precision RTK GNSS receiver.
mosaic-G5 P3H high-reliability receiver tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals.
AIM+ Advanced functionality with jamming and spoofing detection and automatic interference mitigation.
APME+ a posteriori multipath estimator for code and phase multipath mitigation.
LOCK+ superior tracking robustness under heavy mechanical shocks or vibrations
IONO+ provides advanced protection against ionospheric disturbances
RAIM+ receiver autonomous integrity monitoring
In stock
Couldn't load pickup availability
Product Features
Product Features
- M.2 2242 Key A+E compatible (Part of NGFF, Next Generation Form Factor)
- Two antenna inputs with IPEX connectors
- Only USB interface used
- Purple Power LED, green Time pulse LED
- RxTools Control and Analysis Software
- Extensive visualization and evaluation features
- Dimensions 22x42 mm
- Weight: 10 gr.
- Fully assembled, tested and ready to use
Product Comparison
| Description |
| Price |
| Vendor |
| Type |
| Product variants |
| mosaic-G5 P3H M.2 socket dual channel all-constellation multi-frequency top-performance high precision RTK GNSS receiver. mosaic-G5 P3H high-reliability receiver tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals. AIM+ Advanced functionality with jamming and spoofing detection and automatic interference mitigation. APME+ a posteriori multipath estimator for code and phase multipath mitigation. LOCK+ superior tracking robustness under heavy mechanical shocks or vibrations IONO+ provides advanced protection against ionospheric disturbances RAIM+ receiver autonomous integrity monitoring
| Regular price
$417.00
Sale price
$417.00
Regular price
| ELTEHS |
Choose your option
mosaic-G5 P3H Dual Channel M.2 socket RTK GNSS receiver
mosaic-G5 P3H Dual Channel M.2 socket RTK GNSS receiver
Tax excluded
In stock
mosaic-G5 P3H M.2 socket dual channel all-constellation multi-frequency top-performance high precision RTK GNSS receiver.
mosaic-G5 P3H high-reliability receiver tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals.
AIM+ Advanced functionality with jamming and spoofing detection and automatic interference mitigation.
APME+ a posteriori multipath estimator for code and phase multipath mitigation.
LOCK+ superior tracking robustness under heavy mechanical shocks or vibrations
IONO+ provides advanced protection against ionospheric disturbances
RAIM+ receiver autonomous integrity monitoring
- M.2 2242 Key A+E compatible (Part of NGFF, Next Generation Form Factor)
- Two antenna inputs with IPEX connectors
- Only USB interface used
- Purple Power LED, green Time pulse LED
- RxTools Control and Analysis Software
- Extensive visualization and evaluation features
- Dimensions 22x42 mm
- Weight: 10 gr.
- Fully assembled, tested and ready to use
