Receiver type:

• 672-channel u-blox X20 engine
• GPS L1C/A, L2C, L5
• GAL E1B/C, E5a, E6
• BDS B1I, B1C, B2a, B3I
• QZSS L1C/A, L1C/B*, L2C, L5, L6
• NavIC L1*, L5
• SBAS L1C/A

Nav. update rate:

• RTK up to 25 Hz

Position accuracy:

• RTK 0.01 m + 1 ppm CEP
• PPP 0.10 m CEP

Convergence time:

• RTK < 10 sec
• PPP < 120 sec
• Acquisition Cold starts 27 s.
• Aided starts 2 s.
• Reacquisition 2 s.

Sensitivity:

• Tracking & Nav –167
• Cold starts –148 dBm
• Hot starts –157 dBm
• Reacquisition –160 dBm
• Assistance AssistNow Online
• OMA SUPL & 3GPP compliant
• TCXO Oscillator
• Anti-jamming CW detection
• Anti-spoofing Advanced anti-spoofing algorithms and OSNMA
• Built-In RTC crystal
• Flash Memory
• Moving base For attitude sensing and heading applications
• Active and passive antennas Supported
