ZED-F9T-10B L1/L5/E5a 5G InCase PIN timing module with SMA and USB
ZED-F9T-10B L1/L5/E5a 5G InCase PIN timing module with SMA and USB
Tax excluded
ZED-F9T-10B L1/L5/E5a high accuracy timing EVAL module USB, I2C, UART, SPI with SMA antenna connectors. Designed for 5G Network Synchronization. Two time pulse out.
NEW pin to pin compatible version with USB type C connector available ELT0445
The ZED-F9T-10B L1/L5/E5a timing module provides nanosecond-level timing accuracy to the most demanding infrastructure applications. ZED-F9T-10B L1/L5/E5a is designed to meet the most stringent timing synchronization requirements in 5G mobile networks on a global scale. By significantly reducing the time error of the primary source of cellular network synchronization, the ZED-F9T-10B L1/L5/E5a will help operators maximize the performance of their networks and so optimize the return on their investment in 5G communications.
The timing module’s multi-band capability reduces the timing error under clear skies to less than 5 ns without the need for an external GNSS correction service. To further improve accuracy locally, the ZED-F9T-10B L1/L5/E5a features differential timing modes that exchange correction data with other neighboring GNSS timing receivers via a communication network. Multi-band access to all four satellite constellations strengthens the receiver’s capability for delivering more reliable performance. ZED-F9T-10B L1/L5/E5a includes advanced security features such as secure boot, secure interfaces, and T-RAIM to provide the highest level timing integrity. The module has a single RF input for all the GNSS bands and dual SAW filters for exceptional signal selectivity and out-ofband attenuation.
Available in stock (142)
Couldn't load pickup availability
Product Features
Product Features
- On-board low noise 3.3V voltage regulator
- USB, I2C (SDA, SCL), SPI and 2 UART(Tx, Rx) interface, Two time pulse out
- SMA antenna connectors
- u-center u-blox Evaluation Software
- Extensive visualization and evaluation features
- Time pulses 1 and 2: Green LED, GEO: Orange LED, RTK: Red LED
- Backup supercapacitor
- Dimensions: 36x30 mm without SMA
- Weight: 11 gr.
- Fully assembled and ready to use
- 14 pin holes connector
- Mini USB connector
