Receiver type:

• 184-channel u-blox F9 engine
• GPS L1C/A, GLO L1OF, GAL E1B/C, BDS B1I, QZSS L1C/A L1S L5, SBAS L1C/A
• ZED-F9P-0xB: GPS L2C, GLO L2OF, GAL E5b, BDS B2I, QZSS L2C
• ZED-F9P-1xB: GPS L5, GAL E5a, BDS B2a, NavIC L5

Nav. update rate:

• RTK up to 20 Hz1

Position accuracy:

• RTK 0.01 m + 1 ppm CEP
• SPARTN Horizontal pos. accuracy – 0.06m, vert -0.12m

Convergence time:

• RTK < 10 sec
• Acquisition Cold starts 24 s.
• Aided starts 2 s.
• Reacquisition 2 s.
• SPARTN Convergence time - <45sec

Sensitivity:

• Tracking & Nav –167
• Cold starts –148 dBm
• Hot starts –157 dBm
• Reacquisition –160 dBm
• AssistNow GNSS Online
• OMA SUPL & 3GPP compliant
• TCXO Oscillator
• Built-In RTC crystal
• Active CW detection and removal
• Active and passive antennas Supported
• Flash Memory
